Description
The Mark 3HD 6-18x50mm P5 Side Focus TMR 180671 is designed to ensure precision and reliability for shooters and hunters seeking superior optical performance. With a versatile 6x to 18x magnification range, this riflescope is ideally suited for medium to long-range engagements, providing clear and sharp images under various conditions. The large 50mm objective lens allows for optimal light-gathering, enhancing visibility even in low-light scenarios.
Equipped with an exposed elevation turret and counter-clockwise turret rotation, this riflescope offers MIL-based adjustments and a Tactical Milling Reticle (TMR) for accurate holdovers and windage corrections. The 30mm maintube not only ensures ample adjustment for bullet drop and wind drift but also adds to the overall durability of the scope. The side focus feature allows for parallax removal and quick focus on the target, enhancing the shot accuracy.
Built around Leupold's Elite Optical System, the Mark 3HD 6-18x50mm achieves high-definition clarity, superior light transmission, and glare reduction. It is engineered to withstand extreme conditions, being waterproof, fog-proof, and shockproof. The low-profile power selector with an integrated throw lever facilitates quick magnification changes, making this scope a practical choice for dynamic shooting situations. Every aspect of this riflescope is designed with the discerning shooter in mind, offering all-day performance and reliability.
Features:
- OPTIMAL MAGNIFICATION RANGE: 6x to 18x magnification for precise target engagement at various distances.
- LARGE OBJECTIVE LENS: 50mm objective diameter ensures excellent light transmission for clear, bright images.
- ROBUST MAINTUBE: A 30mm maintube provides a strong, shock-resistant platform with ample adjustment capacity.
- PRECISE ADJUSTMENTS: Exposed elevation turret with .1 MIL click adjustments for accurate targeting.
- ELITE OPTICAL SYSTEM: Leupold's superior optics offer high definition, light transmission, and glare reduction.
- SIDE FOCUS CONTROL: Easily accessible parallax adjustment for improved focus and accuracy.
- DURABILITY GUARANTEED: Waterproof, fog-proof, and shockproof construction for reliability in harsh environments.
- TACTICAL MILLING RETICLE: Second focal plane TMR reticle for detailed holdover and windage estimations.
Specifications:
| Specification | Detail |
|---|---|
| Scope Weight | 19.5 ounces |
| Scope Length | 14.6 inches |
| Magnification Range | 6x - 18x |
| Scope Objective Diameter | 50mm |
| Scope Tube Size / Mount | 30mm |
| Turret Adjustment (Click Value) | .1 MIL |
| Elevation Turret Details | Exposed, 5.6 MIL adjustment |
| Windage Turret Details | 5 MIL adjustment |
| Reticle Position | Second focal plane |
| Reticle Details | Tactical Milling Reticle (TMR) |
| Field of View | 6.3 feet @ 100 yards (low), 3 feet @ 100 yards (high) |
| Eye Relief | 5.1" (low), 3.7" (high) |
| Illuminated Reticle | No |
| Scope Finish | Black |
| Scope Turret Rotation | Counter Clockwise (CCW) |
| Product Type | Riflescopes |
| UPC | 030317028640 |
| MPN | 180671 |
WHAT'S IN THE BOX?
- Mark 3HD 6-18x50mm P5 Side Focus TMR 180671 Riflescope
- Lens Covers
- Lens Cloth
- Product Documentation
Our Guarantees
FREE Fast Shipping Over $99
Enjoy complimentary expedited shipping on all orders over $99.
Secure Payments
Shop with confidence using our encrypted payment processing.
High Quality or Money Back
Not satisfied with your purchase? We'll refund your money, no questions asked.
Top-Notch Support
Our expert team is available to answer all your questions and provide assistance.
What Our Customers Say
Optics Knowledge Center
Understanding Rifle Scope Basics
Magnification
Magnification refers to how much larger an object appears through the scope compared to the naked eye. Fixed power scopes have one magnification setting, while variable power scopes offer a range (e.g., 3-9x).
Objective Lens
The objective lens is the front lens that gathers light. Larger objective lenses (measured in mm) gather more light, providing brighter images in low-light conditions but add weight and require higher mounting.
Reticle
The reticle (crosshair) is the aiming point inside the scope. Modern scopes offer various reticle designs, from simple duplex crosshairs to complex ballistic reticles with holdover points for different distances.
Adjustments
Rifle scopes have turrets for windage (horizontal) and elevation (vertical) adjustments. These are measured in MOA (minutes of angle) or MRAD (milliradians) and allow precise aiming adjustments.
Proper Scope Mounting Guide
Select the Right Rings & Base
Choose rings that match your scope's tube diameter (typically 1", 30mm, or 34mm). Select a base compatible with your rifle's receiver. For heavy-recoiling rifles, opt for stronger mounts.
Install the Base
Clean the receiver and base thoroughly. Apply a small amount of blue Loctite to the screws. Attach the base to the receiver and torque the screws to manufacturer specifications.
Attach the Rings
Attach the bottom halves of the rings to the base. Place the scope in the rings and loosely attach the top halves. Don't fully tighten yet.
Set Eye Relief & Level
Position the scope for proper eye relief (3-4 inches) in your normal shooting position. Ensure the reticle is level using a scope leveling tool. Once positioned correctly, tighten the rings evenly in a cross-pattern.
Scope Zeroing Tips
Start Close
Begin zeroing at a shorter distance (25-50 yards) to ensure you're on paper before moving to your desired zero distance (typically 100 yards).
Use a Stable Rest
Always zero your rifle from a stable shooting position using a bench rest, sandbags, or a shooting rest to eliminate as much human error as possible.
Fire Groups
Fire 3-shot groups before making adjustments. This provides a more accurate representation of where your rifle is shooting than single shots.
Make Deliberate Adjustments
Know your scope's adjustment values (typically 1/4 MOA per click). If your group is 2 inches low at 100 yards, you'll need to adjust up 8 clicks (for a 1/4 MOA scope).
Confirm Your Zero
After making adjustments, fire another group to confirm your zero. Repeat the process until your point of impact matches your point of aim.
Document Your Settings
Once zeroed, record your settings including distance, ammunition used, and environmental conditions for future reference.
Optics Maintenance & Care
Cleaning Lenses
- Start by blowing or brushing away loose particles
- Use a lens pen or microfiber cloth for fingerprints
- For stubborn dirt, use lens cleaning solution (never household cleaners)
- Clean with gentle circular motions from center outward
Protecting Your Optics
- Always use lens caps when not in use
- Store in a dry place with silica gel packets
- Avoid extreme temperature changes
- Use a quality scope cover in harsh conditions
Regular Maintenance
- Check and tighten mount screws periodically
- Inspect O-rings and seals for damage
- Verify zero after rough handling
- Clean the exterior with a damp cloth
What to Avoid
- Never use fingers to touch lenses
- Avoid paper products (tissues, paper towels) on lenses
- Don't use acetone, alcohol, or household cleaners
- Never disassemble your scope (voids warranty)
