Description
The Leupold Mark 5HD 5-25x56mm M1C3 FFP Riflescope 176449 is engineered for elite shooters who demand precision and reliability at extreme distances. With a versatile magnification range of 5x to 25x, this scope is an essential tool for anyone serious about long-range marksmanship or competitive shooting. The large 56mm objective lens allows for maximum light transmission, resulting in a clear, bright image even under challenging conditions.
Built to withstand the harshest environments, the Leupold Mark 5HD is both rugged and precise. The first focal plane design means the PR-1MOA illuminated reticle's size changes with the magnification, ensuring accurate shot placement across the entire zoom range. The M1C3 turret system delivers tactile and audible clicks for adjustments, making it effortless to make precise MOA changes for elevation and windage.
Adding sophisticated technology to an already superior design, the Leupold Mark 5HD comes equipped with an illuminated reticle. This feature is critical for low-light scenarios, ensuring that visibility and accuracy are never compromised. The scope's side focus parallax adjustment allows for quick and easy parallax error elimination, providing a sharp reticle for the shooter at varying distances.
Features
- FIRST FOCAL PLANE: Reticle size adjusts with magnification, ensuring accurate ballistic calculations at every power setting.
- HIGH MAGNIFICATION RANGE: 5x to 25x magnification provides versatility for close-range shots and long-range precision.
- LARGE OBJECTIVE LENS: 56mm objective lens diameter allows excellent light transmission for a bright, clear image.
- ILLUMINATED RETICLE: PR-1MOA reticle with illumination enhances target visibility under low light conditions.
- M1C3 TURRETS: Delivers precise, tactile MOA adjustments with a three-turn dial for rapid dialing of elevation and windage.
- SIDE FOCUS: Convenient side focus for easy parallax adjustment without changing your shooting position.
- RUGGED CONSTRUCTION: Durable build quality suited for harsh conditions without compromising on performance.
- LONG EYE RELIEF: Generous eye relief offers comfortable viewing and safeguards against recoil injury.
Specifications
| Feature | Specification |
|---|---|
| Scope Weight | 30 oz. |
| Scope Length | 15.67" |
| Magnification Range | 5 - 25x |
| Scope Objective Diameter | 56mm |
| Scope Tube Size / Mount | 35mm |
| Turret Adjustment | 0.25 MOA |
| Elevation Turret Details | 120 MOA, M1C3 |
| Windage Turret Details | 60 MOA |
| Parallax Adjustment | 50 yards - infinity |
| Reticle Position | First Focal Plane |
| Reticle Details | Illum. PR-1MOA |
| Field of View | 20.5 - 4.2 ft. per 100 yd |
| Exit Pupil | 2.2 mm |
| Eye Relief | 3.58" - 3.82" |
| Illuminated Reticle | Yes |
| Scope Finish | Black |
| Scope Turret Rotation | Counter Clockwise (CCW) |
| Product Type | Riflescopes |
| UPC | 030317021085 |
| MPN | 176449 |
Included In The Box
- Leupold Mark 5HD 5-25x56mm M1C3 FFP Riflescope 176449
- Lens Covers
- Lens Cloth
- Product Documentation
Leupold is renowned for manufacturing high-quality optics, and the Mark 5HD 5-25x56mm M1C3 FFP Riflescope stands as a testament to their dedication to precision and durability. This model features top-tier glass and meticulous construction, ensuring that it meets the stringent demands of professional marksmen and tactical experts.
Our Guarantees
FREE Fast Shipping Over $99
Enjoy complimentary expedited shipping on all orders over $99.
Secure Payments
Shop with confidence using our encrypted payment processing.
High Quality or Money Back
Not satisfied with your purchase? We'll refund your money, no questions asked.
Top-Notch Support
Our expert team is available to answer all your questions and provide assistance.
What Our Customers Say
Optics Knowledge Center
Understanding Rifle Scope Basics
Magnification
Magnification refers to how much larger an object appears through the scope compared to the naked eye. Fixed power scopes have one magnification setting, while variable power scopes offer a range (e.g., 3-9x).
Objective Lens
The objective lens is the front lens that gathers light. Larger objective lenses (measured in mm) gather more light, providing brighter images in low-light conditions but add weight and require higher mounting.
Reticle
The reticle (crosshair) is the aiming point inside the scope. Modern scopes offer various reticle designs, from simple duplex crosshairs to complex ballistic reticles with holdover points for different distances.
Adjustments
Rifle scopes have turrets for windage (horizontal) and elevation (vertical) adjustments. These are measured in MOA (minutes of angle) or MRAD (milliradians) and allow precise aiming adjustments.
Proper Scope Mounting Guide
Select the Right Rings & Base
Choose rings that match your scope's tube diameter (typically 1", 30mm, or 34mm). Select a base compatible with your rifle's receiver. For heavy-recoiling rifles, opt for stronger mounts.
Install the Base
Clean the receiver and base thoroughly. Apply a small amount of blue Loctite to the screws. Attach the base to the receiver and torque the screws to manufacturer specifications.
Attach the Rings
Attach the bottom halves of the rings to the base. Place the scope in the rings and loosely attach the top halves. Don't fully tighten yet.
Set Eye Relief & Level
Position the scope for proper eye relief (3-4 inches) in your normal shooting position. Ensure the reticle is level using a scope leveling tool. Once positioned correctly, tighten the rings evenly in a cross-pattern.
Scope Zeroing Tips
Start Close
Begin zeroing at a shorter distance (25-50 yards) to ensure you're on paper before moving to your desired zero distance (typically 100 yards).
Use a Stable Rest
Always zero your rifle from a stable shooting position using a bench rest, sandbags, or a shooting rest to eliminate as much human error as possible.
Fire Groups
Fire 3-shot groups before making adjustments. This provides a more accurate representation of where your rifle is shooting than single shots.
Make Deliberate Adjustments
Know your scope's adjustment values (typically 1/4 MOA per click). If your group is 2 inches low at 100 yards, you'll need to adjust up 8 clicks (for a 1/4 MOA scope).
Confirm Your Zero
After making adjustments, fire another group to confirm your zero. Repeat the process until your point of impact matches your point of aim.
Document Your Settings
Once zeroed, record your settings including distance, ammunition used, and environmental conditions for future reference.
Optics Maintenance & Care
Cleaning Lenses
- Start by blowing or brushing away loose particles
- Use a lens pen or microfiber cloth for fingerprints
- For stubborn dirt, use lens cleaning solution (never household cleaners)
- Clean with gentle circular motions from center outward
Protecting Your Optics
- Always use lens caps when not in use
- Store in a dry place with silica gel packets
- Avoid extreme temperature changes
- Use a quality scope cover in harsh conditions
Regular Maintenance
- Check and tighten mount screws periodically
- Inspect O-rings and seals for damage
- Verify zero after rough handling
- Clean the exterior with a damp cloth
What to Avoid
- Never use fingers to touch lenses
- Avoid paper products (tissues, paper towels) on lenses
- Don't use acetone, alcohol, or household cleaners
- Never disassemble your scope (voids warranty)
