Description
The Holosun HS507K X2 Reflex Red Dot Sight is a cutting-edge optic designed specifically for concealed carry pistols. The HS507K-X2 model embodies technological advancements and user-friendly features that cater to both novice shooters and experienced firearms enthusiasts. With Lock Mode, this sight enters a state of heightened security, where manual buttons are disabled to prevent inadvertent changes during critical situations or when holstered.
Built to last, the Holosun HS507K X2 is equipped with a Super LED that delivers a crisp, clear reticle. The innovative Multi-Reticle System (MRS) allows users to choose between a 2 MOA Dot, a 32 MOA Circle, or a Circle-Dot reticle. This customization ensures peak performance in various shooting conditions. Furthermore, the optic boasts remarkable battery life, capable of up to 50,000 hours, minimizing the need for frequent replacements and ensuring readiness at all times.
Durability and practicality are central to the design. Accommodating for varied lighting environments, the sight includes 12 brightness settings, two of which are night vision compatible. The Shake Awake feature lies dormant until the sight detects movement, conserving battery life. The solar failsafe system provides additional assurance, as it continues to power the reflex sight in the event of battery failure. Waterproof to the IP67 standard, the HS507K X2 is fully resistant to the elements. These features combined make the Holosun HS507K X2 a reliable tool for fast, accurate targeting.
Holosun HS507K Features
- LOCK MODE SECURITY: Avoid unintentional setting changes with the advanced Lock Mode feature.
- SUPER LED DISPLAY: Experience clarity and longevity with Holosun's Super LED and up to 50,000-hour battery life.
- MULTIPLE RETICLE CHOICES: Customize your view with the Multi-Reticle System, offering a 2 MOA Dot, 32 MOA Circle, or Circle-Dot.
- BRIGHTNESS VARIABILITY: Adapt to any light with 12 brightness settings, including two night vision compatible modes.
- SHAKE AWAKE TECHNOLOGY: Conserve power efficiently with automatic wake-up at the first sign of movement.
- SOLAR FAILSAFE: Stay powered under the sun with the innovative solar backup system.
- WATERPROOF DURABILITY: Rely on the IP67 waterproof rating for performance in harsh conditions.
- CONVENIENT BATTERY ACCESS: Quick battery changes thanks to the handy tray battery compartment.
Holosun HS507K Specifications
| Specification | Detail |
|---|---|
| Model | 507 |
| Footprint | Holosun K Series |
| Weight | 1 oz |
| Length | 1.6 inches |
| Mount | Not Included |
| Magnification Range | 1x |
| Reticle Size | 2 MOA Dot & 32 MOA Circle |
| Reticle Color | Red |
| Parallax Adjustment | Free |
| Eye Relief | Unlimited |
| Adjustment Graduation | 1 MOA |
| Elevation Adjustment | ±30 MOA |
| Windage Adjustment | ±30 MOA |
| Package Includes | Multi-Tool, User Manual, Lens Cloth |
| Finish | Black |
| Dimensions | 1.6 x 0.98 x 0.95 inches |
| Night Vision Compatible | Yes |
| Brightness Settings | 2 NVD & 10 DL |
| Battery | CR1632 |
| Battery Life | Up to 50,000 Hours |
| Item Condition | New |
| UPC | 810047071211 |
| MPN | HS507K-X2 |
| Product Type | Red Dot Sights |
WHAT'S IN THE BOX?
- HS507K X2 Reflex Sight
- CR1632 Battery
- User Manual
- Lens Cloth
- Multi-Tool
Our Guarantees
FREE Fast Shipping Over $99
Enjoy complimentary expedited shipping on all orders over $99.
Secure Payments
Shop with confidence using our encrypted payment processing.
High Quality or Money Back
Not satisfied with your purchase? We'll refund your money, no questions asked.
Top-Notch Support
Our expert team is available to answer all your questions and provide assistance.
What Our Customers Say
Optics Knowledge Center
Understanding Rifle Scope Basics
Magnification
Magnification refers to how much larger an object appears through the scope compared to the naked eye. Fixed power scopes have one magnification setting, while variable power scopes offer a range (e.g., 3-9x).
Objective Lens
The objective lens is the front lens that gathers light. Larger objective lenses (measured in mm) gather more light, providing brighter images in low-light conditions but add weight and require higher mounting.
Reticle
The reticle (crosshair) is the aiming point inside the scope. Modern scopes offer various reticle designs, from simple duplex crosshairs to complex ballistic reticles with holdover points for different distances.
Adjustments
Rifle scopes have turrets for windage (horizontal) and elevation (vertical) adjustments. These are measured in MOA (minutes of angle) or MRAD (milliradians) and allow precise aiming adjustments.
Proper Scope Mounting Guide
Select the Right Rings & Base
Choose rings that match your scope's tube diameter (typically 1", 30mm, or 34mm). Select a base compatible with your rifle's receiver. For heavy-recoiling rifles, opt for stronger mounts.
Install the Base
Clean the receiver and base thoroughly. Apply a small amount of blue Loctite to the screws. Attach the base to the receiver and torque the screws to manufacturer specifications.
Attach the Rings
Attach the bottom halves of the rings to the base. Place the scope in the rings and loosely attach the top halves. Don't fully tighten yet.
Set Eye Relief & Level
Position the scope for proper eye relief (3-4 inches) in your normal shooting position. Ensure the reticle is level using a scope leveling tool. Once positioned correctly, tighten the rings evenly in a cross-pattern.
Scope Zeroing Tips
Start Close
Begin zeroing at a shorter distance (25-50 yards) to ensure you're on paper before moving to your desired zero distance (typically 100 yards).
Use a Stable Rest
Always zero your rifle from a stable shooting position using a bench rest, sandbags, or a shooting rest to eliminate as much human error as possible.
Fire Groups
Fire 3-shot groups before making adjustments. This provides a more accurate representation of where your rifle is shooting than single shots.
Make Deliberate Adjustments
Know your scope's adjustment values (typically 1/4 MOA per click). If your group is 2 inches low at 100 yards, you'll need to adjust up 8 clicks (for a 1/4 MOA scope).
Confirm Your Zero
After making adjustments, fire another group to confirm your zero. Repeat the process until your point of impact matches your point of aim.
Document Your Settings
Once zeroed, record your settings including distance, ammunition used, and environmental conditions for future reference.
Optics Maintenance & Care
Cleaning Lenses
- Start by blowing or brushing away loose particles
- Use a lens pen or microfiber cloth for fingerprints
- For stubborn dirt, use lens cleaning solution (never household cleaners)
- Clean with gentle circular motions from center outward
Protecting Your Optics
- Always use lens caps when not in use
- Store in a dry place with silica gel packets
- Avoid extreme temperature changes
- Use a quality scope cover in harsh conditions
Regular Maintenance
- Check and tighten mount screws periodically
- Inspect O-rings and seals for damage
- Verify zero after rough handling
- Clean the exterior with a damp cloth
What to Avoid
- Never use fingers to touch lenses
- Avoid paper products (tissues, paper towels) on lenses
- Don't use acetone, alcohol, or household cleaners
- Never disassemble your scope (voids warranty)
